#ET-7A(W) Smart Thermostat adopts a 3.5” color capacitive touch screen, 2.4G and 5G Wifi available, and it is suitable for water floor heating systems and electric floor heating systems.
Vertical Frame Structure With Secure Back Cover Design;
Top-class Relay, VA Screen, Touch Key, Support 100,00+ times Use;
Built-in Class A GFCI Module for North America, Non-GFCI version available in other regions;
2.4G and 5G Wi-Fi Module Available, Support Voice Control By Alexa and Google Home;
Programmable events 7&5+1+1, ETL Approved.
#ET-7A(W) is the latest design for electric floor heating systems in the United States and Canada. Developed and manufactured according to UL and CSA certification standards, ETL approved.
Vertical Frame, Secure Back Cover Design;
VA Screen, Touch Key, Support Wi-Fi Function;
Mechanical Turn On/ Off Switch On The Top;
Three Versions Available: With 2.4G/2.4G & 5G Wi-Fi Module Or Without Wi-Fi Module;
Warmme™APP Assist You To Set The Thermostat Remotely;
New User Operation Guide Program;
Room Sensor and Floor Sensor.
Approved By ETL, according to UL and CSA certification standards;
7 / 5+1+1 Day Programming, 4 Events/Day;
Built-in Class A, 5mA GFCI module and Non-GFCI version available;
Mode: Auto / Manual / Anti-frozen;
Voice control, Weather shows;
IP Rating: IP21
| Technical Data | |
| Application | Smart Thermostat For Electric Floor Heating System |
| Installation | Fits a standard flush box, bracket, or c-clip. |
| Power supply voltage | 120V-240V 50/60Hz |
| Maximum load current | 15 A |
| Wifi Module | 5G+2.4G |
| IP rating | IP21 |
| Temperature Range | +5 / +40℃ |
| Floor Sensor | 10ft(3m) |
| Dimensions(W/H/D) | 5.1''/3.2''/1.97'' |
| Wall box(W/H/D) | 3''/2''/2'' |
| Approve | ETL approved; Built-in Class A 5mA GFCI |
| Warranty | 2 years |
